Hitachi Travelstar 5K250-160

Posted by DeviceLog.com | တွင်တင်ထားသည်။ HDD ပါ။ | တွင်တင်ခဲ့သည်။ 2012-05-24

2

The product in these pictures is OEM product. Hitachi Travelstar 5K250 is 2.5-inch hard disk drive with capacities of 250GB, 160GB 120GB and 80GB. HTS542516K9A300 has two platter, three heads and data capacity of 160GB.

  • Product Name : 5K250-160
  • Model Number : HTS542516K9A300
  • ထုတ်လုပ်သူ : Hitachi Global Storage Technologies
  • ထုတ်လုပ်သည့်နိုင်ငံ : Thailand
  • Build Year/Week : 2008/04
  • Interface : SATA2 (3Gbits/s)
  • ဒေတာစွမ်းရည်: 160GB (125GB/platter)
  • Buffer Capacity: 8MB (Upper 736KB is used for firmware)
  • Rotational Speed : 5400RPM
  • Number of Disk : 2
  • Number of Heads : 3
  • Coding : 100/102 2it parity (199/200 RC Modulation Encoding)
  • Media Transfer Rate(max) : 619Mbits/s
  • Average Seek Time : 11ms for read, 13ms for write
  • Power on to ready(typical) : 3.5sec
  • Sector Size : 512Bytes
  • အရွယ်အစား : (69.85±0.25)✕(100.2±0.25)✕(9.5±0.2)mm
  • Weight : 102ဆ
  • Noise : Idle 24dB / Seek 26dB
  • Input Voltage : +5VDC (±5%)
  • Power Consumption : Startup(maximum peak) 5.0W / Read or Write 1.8W / Seek 2.2W / Active Idle 0.8W / Low Power Idle 0.55W / Standby 0.2W / Sleep 0.1W
  • Operating Case Temperature Range : 5~55℃
  • Non-operating Ambient Temperature : -40~65℃

မှတ်ချက်များ (2)

hello ,

Where to get the firmware for this hard disk ?

I do not know whether there is easy method to replace the firmware of this hard disk.
